ABS Sensor 8972067600 For Isuzu 700P 4HE1 4HG1 4HK1

An anti-lock braking control system is described in which the braking pressure cycle is filtered by limiting the minimum time period of each brake pressure cycle.The fit between the sensor and the hub unit's outer ring includes interference fit and nut locking. The linear wheel speed sensor is mainly in the form of nut locking, while the ring wheel speed sensor adopts interference fit. Distance between the permanent magnet body surface and the tooth surface of the tooth ring: 0.5 ± 0.1 5mm (mainly ensured by controlling the outer diameter of the tooth ring, the inside diameter of the sensor and the concentricity)

Send Inquiry

An anti-lock braking control system is described in which the braking pressure cycle is filtered by limiting the minimum time period of each brake pressure cycle.Abs sensor is used in the anti-Lock Braking System (ABS) of motor vehicles. In the ABS System, the car's speed is monitored mostly by an inductive sensor. The ABS sensor outputs a group of quasi-sinusoidal AC electric signals by acting on the tooth ring that rotates synchronously with the wheel, and the frequency and amplitude are related to the wheel speed.The output signal is transmitted to THE ABS Electronic control unit (ECU) to realize real-time monitoring of wheel speed.

Product Details

Brand Name：China aftermarkets

Product Name : ABS SENSOR

Factory Number：8-97206760-2

Engine Model：4HK1

OE Number： 8972067600

Vehicle Model ：700P/4HK1/4HE1/4HG1

Place of Origin: China

Actual size:400*43*15

Quality guarantee

Time of delivery: 10 to 15 days

Parts number
